Rugged and temperature-durable on-board computers for rolling stock applications. Used for driver’s desk, control of passenger information system, surveillance system control/display unit or diagnostics and communication units.
- No moving parts (fan or HDD)
- Operation system Linux or Windows
- Intel and ARM version
- Waterproof variant
- Wide operating temperature range -40 °C to 70 °C
- Wide range of power supply voltages
- 24 V / 36 V / 72V / 110 V (-30 % to +25 %)
| PWxxx | PPX17xxx | |
|---|---|---|
| Processor | Intel ATOM x6414RE Quad Core, 4× 1.5GHz, 4GB RAM, 32GB ARM Cortex A-53, Quad Core, 4× 1.6 GHz, 2 GB LPDDR4, 4 GB |
Intel Core i7-8850H, 6 cores, 2.6 GHz eMMC FLASH |
| FLASH | None / CFast slot / mSATA | None / SD slot / mSATA / 2.5" SSD |
| Operation system | None / Linux / Windows | |
| USB | 2 × USB 2.0 type A, 1 × USB 2.0 M12, 5-pin, A-code | 1 × USB 3.0 type A, 1 × USB 2.0 M12, 5-pin, A-code |
| Audio | None / Stereo input / Stereo output | - |
| Ethernet interface | 1 / 2 × Ethernet 10 / 100 Mbps (M12, D-coded) | 2 × 1 Gbps, connector M12 8-pin X-coded, socket |
| RS232 | None / 1 × | |
| RS485 | None / 1 × / 2 × / 1 × RS422 | - |
| CAN | None / 1 × / 2 × | - |
| MVB | None / 1 × | - |
| Wireless | Wi-Fi - None / 1 × 802.11a/b/g/n/ac (2.4, 5 GHz) GPS - None / 1 × GPS GLONASS GSM - None / 1 × 2G / 3G / 4G (LTE) |
- |
| Power supply | 24 V / 36 V / 72V / 110 V (-30 % to +25 %) | 16.8 V to 50.4 V DC |
| Protection | IP65 / IP20 | |
| Operating temperature range | -40 °C to 70 °C | |
| Mounting | On the base plate | |
| Weight | Typ. 4.00 kg | Typ. 9.7 kg |
| Standards | EN 50155, EN 50121-3-2, EN 45545-2 |
|---|
PWxxx
Processor:
Intel ATOM x6414RE Quad Core, 4× 1.5GHz, 4GB RAM, 32GB ARM Cortex A-53, Quad Core, 4× 1.6 GHz, 2 GB LPDDR4, 4 GB
FLASH:
None / CFast slot / mSATA
Operation system:
None / Linux / Windows
USB:
2 × USB 2.0 type A, 1 × USB 2.0 M12, 5-pin, A-code
Audio:
None / Stereo input / Stereo output
Ethernet interface:
1 / 2 × Ethernet 10 / 100 Mbps (M12, D-coded)
RS232:
None / 1 ×
RS485:
None / 1 × / 2 × / 1 × RS422
CAN:
None / 1 × / 2 ×
MVB:
None / 1 ×
Wireless:
Wi-Fi - None / 1 × 802.11a/b/g/n/ac (2.4, 5 GHz) GPS - None / 1 × GPS GLONASS GSM - None / 1 × 2G / 3G / 4G (LTE)
Power supply:
24 V / 36 V / 72V / 110 V (-30 % to +25 %)
Protection:
IP65 / IP20
Operating temperature range:
-40 °C to 70 °C
Mounting:
On the base plate
Weight:
Typ. 4.00 kg
PPX17xxx
Processor:
Intel Core i7-8850H, 6 cores, 2.6 GHz eMMC FLASH
FLASH:
None / SD slot / mSATA / 2.5" SSD
Operation system:
None / Linux / Windows
USB:
1 × USB 3.0 type A, 1 × USB 2.0 M12, 5-pin, A-code
Audio:
-
Ethernet interface:
2 × 1 Gbps, connector M12 8-pin X-coded, socket
RS232:
None / 1 ×
RS485:
-
CAN:
-
MVB:
-
Wireless:
-
Power supply:
16.8 V to 50.4 V DC
Protection:
IP65 / IP20
Operating temperature range:
-40 °C to 70 °C
Mounting:
On the base plate
Weight:
Typ. 9.7 kg
Standards
Standards:
EN 50155, EN 50121-3-2, EN 45545-2
