OLED displays are used as reservation system terminals for open passenger carriages in railway rolling stock. The customer can adjust and finish the vehicle reservation system themselves as needed in the specific project.
- CANopen / RS485
- Wide operating temperature range -40 °C to 70 °C
- EN 50155 compliant
| LCD Displays | AMT3010/A1 |
|---|---|
| Display | OLED |
| Backlight, colour | YELLOW |
| Size | 128 × 64 pixels |
| Communication | 1 × RS485 |
| Power supply | 16.8 V DC to 50.4 V DC |
| Operating temperature | -40 °C to 70 °C |
| Mounting | To the shelf frame, 2× M4 screw |
| Standards | EN 50155, EN 50121-3-2, EN 45545-2 |
AMT3010/A1
Display:
OLED
Backlight, colour:
YELLOW
Size:
128 × 64 pixels
Communication:
1 × RS485
Power supply:
16.8 V DC to 50.4 V DC
Operating temperature:
-40 °C to 70 °C
Mounting:
To the shelf frame, 2× M4 screw
Standards
Standards:
EN 50155, EN 50121-3-2, EN 45545-2
