Dot matrix information panels are designed for passenger information systems. There are exterior and interior panel versions available. The LED panels are ideal for rolling stock applications due to the extremely wide range of operating temperatures and their robust and durable design.
- Variable mechanical versions
- Light sensor / Automatic brightness control
- RS485 interface
- Ethernet interface
- Integrated WC symbol as option
- Wide operating temperature range -40 °C to 70 °C
- UIC 176 versions available
- TSI PRM compliant
- EN 50155 compliant
| LED panels common parameters | Specifications |
|---|---|
| Display | LED |
| LED colour | Yellow - 590 nm typ., Red - 633 nm typ., White (different color options on demand), RGB |
| Resolution | Optional |
| Pitch (mm) | 4 / 5 / 6 / 8 |
| Front panel protection | Open frame / IP30 / IP65 |
| Brightness | Internal - typ. 200 cd/m², External - typ. 800 cd/m² |
| Light sensor | Automatic brightness control |
| Interface | RS485 / Ethernet |
| Galvanic isolation | Yes |
| Power supply | 24 V DC / 110 V DC |
| Cover color | Typically RAL7035, RAL9005 (different color options on demand) |
| Operating temperature range | -40 °C to 70 °C |
| Standards | EN 50155, EN 50121-3-2, EN 45545-2 |
LED Panels Common Parameters
Display:
LED
LED colour:
Yellow - 590 nm typ., Red - 633 nm typ., White (different color options on demand), RGB
Resolution:
Optional
Pitch (mm):
4 / 5 / 6 / 8
Front panel protection:
Open frame / IP30 / IP65
Brightness:
Internal - typ. 200 cd/m², External - typ. 800 cd/m²
Light sensor:
Automatic brightness control
Interface:
RS485 / Ethernet
Galvanic isolation:
Yes
Power supply:
24 V DC / 110 V DC
Cover color:
Typically RAL7035, RAL9005 (different color options on demand)
Operating temperature range:
-40 °C to 70 °C
Standards
Standards:
EN 50155, EN 50121-3-2, EN 45545-2
RGB LED - ROUTE MAP DISPLAYS
| Type | Resolution | Pitch (mm) | Colour | Brightness (cd/m²) | Dimensions (mm) | Front panel protection | UIC 176 |
|---|---|---|---|---|---|---|---|
| Interface: Ethernet | |||||||
| DLM100/A | 1 x 40 | 1 x | RGB | 800 | (720 x 98 x 27) | IP00 | - |
| AIPB1A0L103K0NA: EN 50155, EN 50121-3-2, EN 45545-2 | |||||||
DLM100/A (Interface: Ethernet)
Resolution:
1 x 40
Pitch (mm):
1 x
Colour:
RGB
Brightness (cd/m²):
800
Dimensions (mm):
(720 x 98 x 27)
Front panel protection:
IP00
UIC 176:
-
AIPB1A0L103K0NA
Standards:
EN 50155, EN 50121-3-2, EN 45545-2
